| Model | HPD800T4X4 | HPD1200T4X5 | HPD1400T4X6 |
| Norminal Pressure (KN) | 8000 | 12000 | 14000 |
| Unit Pressure (kg/cm2) | 53.8 | 64.6 | 62.8 |
| Main Oil Cylinder (mmxpcs) | Φ320x4 | Φ400x4 | Φ340x4 |
| Lift Oil Cylinder (mmxpcs) | Φ63x4 | Φ63x2 | Φ63x2 |
| Hot Plate Size (mm) | 1400x1400 | 1400x1650 | 1400x2000 |
| Finished Size (mm) | 1250x1250 | 1250x1530 | 1250x1830 |
| Hot Plate Thickness (mm) | 100/100 | 100/100 | 100/100 |
| Thickness of Frame (mmxpcs) | 40x4 | 70(80)x4 | 80(90)x4 |
| Heat Consumption (kcal/h) | 100,000 | 120,000 | 150,000 |
| Pumping Motor Power (kW) | 22 | 22 | 22 |
| OverallDimension (m) | 2.4x1.4x4.4 | 2.65x1.4x4.4 | 3.2x1.4x4.5 |
